Twinmotion Direct Link Plugin for SketchUp

Twinmotion helps to create gorgeous high-resolution stills. In addition, this software helps to create high-quality videos and provides real-time experiences for the users. Twinmotion helps to support the files for Building Information modelling software, CAD, and modelling solutions. This software also offers direct one-click synchronization with many of the other software which helps to take the design project to the next level.

A wide range of plugins has been offered by Twinmotion which helps to streamline the design workflow. These Twinmotion plugins include:

CityEngine Plugin

This plugin is used to enable the users to preserve the materials, geometry and metadata of the 3D models and to import those 3D scenes into the Unreal engine. The import of the 3D models has been done with minimal loss of quality through this Twinmotion plugin. CityEngine scenes can be imported into Datasmith file format which allows the preservation of complex and large-scale CityEngine scenes.

Form-Z Plugin

This plugin makes it easy to export the project to Twinmotion software. In this plugin, users can synchronize their project with a Direct Link. In this regard, the changes made by the users can be reflected in the Twinmotion software immediately.

Twinmotion Direct Link

Twinmotion Direct Link plugin allows the users to synchronize BIM information as well as geometry from SketchUp Pro to Twinmotion with just a single click.

Navisworks Plugin

The Navisworks plugin of Twinmotion enables the users to import entire scenes from this plugin. These plugins are also used for Unreal Engine. In the case of downloading the latest plugins from the page of Unreal Engine, the reinstallation of those plugins for Twinmotion is not required.

Details about Twinmotion Direct Link

Users can use the Datasmith Direct Link workflow for importing the design assets or 3D scenes on the design applications. The functionality of the Datasmith Direct Link workflow can be used after installing the Datasmith Exporter plugin. In one Twinmotion project, multiple direct links can be created which helps to allow the users to import and mix the files from different applications.

How to set a Datasmith Direct Link

➢ For setting up a Datasmith Direct Link, users have to download the Datasmith Exporter plugin first for their design applications. These plugins can be accessed on the Twinmotion website, the Plugins tab on the home panel of Twinmotion, or the design application websites.
➢ The next step is installing the plugins for the design applications of the users.
➢ After installing the plugins, the design scenes are opened for setting a Datasmith Direct Link.
➢ The next step is opening the Import dock. This can be done by clicking the import option from the footer.
➢ The import icon from the import dock has been clicked.
➢ After that, the direct link tab has been selected. This shows the filename of the open sources, from which, users can select the scenes as per their needs.
➢ In the option feature, users can select the Direct Link importing options and then click import option which helps to import the content from the design application into the Twinmotion software.
➢ Users can click the Synchronize with Direct Link on the Datasmith Exporter toolbar which helps to start the synchronization process of direct link and the scenes can be opened in Twinmotion software.

How to set multiple Datasmith Direct Link

A separate instance of the design application must be open for each of the direct links which helps to set more than one Direct Link to the multiple design applications.

How can update a scene in Twinmotion?

For updating a scene in the Twinmotion software, a direct link needs to be set up between the Twinmotion and the design applications of the users. This setup enables the users to make changes in their scenes automatically or manually with the help of the Synchronize with Direct Link feature.

How can use the Direct Link Auto Sync Feature?

The Direct Link Auto Sync button should be clicked by the users in their design applications to enable the Direct Link Auto Sync feature. In the case of Archicad and SketchUp Pro, the button background switches to light blue while enabling the Direct Link Auto Sync Feature.

How can use the Synchronize along with the Direct Link Feature?

Users can make changes to the scenes in their design applications in case of having a Direct Link set up between the Twinmotion software and the design applications. Users can manually update the scenes by clicking the Synchronize with Direct Link button on the Datasmith Exporter toolbar.

Sketchup 2020 and Twinmotion

To learn more, watch the following video tutorial.

Video Source: Garden Design Tools for Professionals

Sketchup 2020 and Twinmotion, both can be used directly for creating high-quality videos, images as well as virtual reality presentations. The designs from Sketchup 2020 can be imported directly into Twinmotion by following these steps:

➢ Opening the Twinmotion and selecting the import option
➢ Selecting the Sketchup designs as per the needs and according to the file types of the users
➢ Locating the saved models thus importing the 3D objects for Twinmotion objects.
